AT200 數顯附著力測試儀
用一個定子黏貼到涂層表面測試涂層和基材的附著力。特性：
- 操作簡單
- 適用于實驗室和現場
- 四種定子可選
- 量程可以達到60MPa, 精度是全量程的±2%
- 單位：MPa,psi和bar
- 臨近極限值聲音報警
- 可充電電池供電
執行標準:
ASTM D 4541, ISO 4624, ISO16276-1
技術參數
| 產品型號 | AT200-10 | AT200-14 | AT200-20 | AT200-50 |
| 量 程 | 10mm定子 | 14mm定子 | 20mm定子 | 50mm定子 |
| 2.5 - 60 MPa | 1.3 - 30 MPa | 0.8 - 15 MPa | 0.2 - 2.4 MPa | |
| 精 度 | 全量程±2% | |||
| 尺 寸 | 86 x 153 mm | |||
| 重 量 | 2500 g | |||
| 供 電 | 1個充電電池 | |||
| 裝 箱 單 |
AT200,膠水，支撐環，定子刀，包裝盒，說明書和合格證 AT200-10/14/20:20個相應尺寸的定子 AT200-50：8個50毫米直徑的定子 |
|||
配件
| 配件型號 | 描述 |
| AT200-10D | 10mm定子(10個/包) |
| AT200-14D | 14mm定子(10個/包) |
| AT200-20D | 20mm定子(10個/包) |
| AT200-50D | 50mm定子(8個/包) |
| AT200-50F | 固定環 |
| AT200-AD | 膠水 |
Technical Data
| Part Number | AT200-10 | AT200-14 | AT200-20 | AT200-50 |
| Range | 10 mm dolly | 14 mm dolly | 20 mm dolly | 50 mm dolly |
| 2.5 - 60 MPa | 1.3 - 30 MPa | 0.8 - 15 MPa | 0.2 - 2.4 MPa | |
| Accuracy | ±2% of full scale | |||
| Dimensions | 86 x 153 mm | |||
| Weight | 2500 g | |||
| Battery | One pc rechargeable battery | |||
| Packing List |
AT200-10, AT200-14, AT200-20: AT200 adhesion tester, 20 pcs of 20 mm dollies, adhesive, support ring, dolly cutter, carry case, operation manual, certification. AT200-50: all are the same as above except 8 pcs of 50 mm dollies and one pc fix ring. |
|||
Accessories
| Part Number | Description |
| AT200-10D | Spare dollies 10 mm diameter (pack of 10) |
| AT200-14D | Spare dollies 10 mm diameter (pack of 10) |
| AT200-20D | Spare dollies 10 mm diameter (pack of 10) |
| AT200-50D | Spare dollies 10 mm diameter (pack of 8) |
| AT200-50F | Fix ring |
| AT200-AD | Adhesive |
