產品名稱:土壤含水率測試儀
型號:T-S-30
廠家:美國NDT James
美國NDT James T-S-30 Aquaprobe微波土壤含水率測試儀代表著現代水分測量技術的突破。利用最新的微波及微型處理器技術,
T-S-30 Aquaprobe微波土壤含水率測試儀可測量泥土及幼細聚合物的水含量。簡單地將五根叉子插入泥土去量度及檢視水分百份比。同時提供特別的使用指引,
讓使用者將叉插入特定密度的泥土。
The James Aquaprobe? T-S-30 Soil Moisture
Meter
A microwave meter for rapid determination of moisture content
in different types of soils.
-
Highway and Road Contractors
-
Geotechnical Engineering
-
Foundation Engineering
-
Golf Courses
-
Earth Moving Works
-
Agriculture
Features & Benefits
· Fast and easy to use.
· No hazardous chemicals.
· Accurate.
· Completely portable.
· Easy to read display.
· Instantaneous readings.
Product Information
The James Aquaprobe? represents a break-through in modern
moisture measurement technology. By utilizing the latest microwave and
microprocessor technology, the Aquaprobe? can determine the soil moisture
content of different types of soils and other fine aggregate. Simply insert the
five prongs in the soil to be measured and review the percentage moisture on
display. A special guide is supplied to assist the user with inserting the
prongs in particularly dense soil.
The Aquaprobe? Microwave Soil Moisture Meter uses a five
prong sensor to measure the complex dielectric constant of the material
encompassed by the outer four prongs. As the dielectric constant of water is
four to eight times greater than most natural soil types, changes in water
content directly affect the sensor output. This output is then converted by the
integrated microprocessor and moisture content is displayed directly as a
percentage of dry weight. An average of five to ten readings is normally taken
in order to ensure a valid reading, especially as water does not distribute
itself evenly for many types of materials.
The basic unit comes pre-calibrated for Lean Clay, Silt, Sand (Ottawa Sand
and SP sand) and general type of Silty Sandy soil. These soils represent the
most commonly found types. This makes the basic unit the economical choice when
evaluating soil moisture levels.
The complete system includes equipment to create custom calibration curves
for different types of soil. The instrument can be programmed with up to ten
different materials by the user. For highest accuracy, the unit should be
programmed for the material being tested. Simple to use Windows? software is
provided for calibrating the unit to the various materials.
Finally, the Aquaprobe? instrumentation unit can store over 150
readings. Storage is complete with the time and date for future reference. Data
can be recalled via USB interface to a personal computer running Windows?.
Specifications
|
Probe
|
|
|
Measurement Range
|
0 - 15% by Dry Weight
|
|
Frequency:
|
50 Mhz
|
|
Power:
|
2 AA Batteries
|
|
Display:
|
4 x 16 Char. Trans - reflective
|
|
Data Link:
|
USB
|
|
Weight:
|
4 lbs. (1.8 kg)
|
